O W N E R ’ S M A N U A L

MINI WEATHER

FORECAST STATION

Model AH-1993

– 1 –

– 2 –

– 3 –

– 4 –

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

– 5 –

– 6 –

– 7 –

– 8 –

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

ENGLISH

FUNCTION

• Calendar: hour minute year month day and week (up to 2052);

- With 12/24 time format;

- Alarm with snooze function;

- Temperature and humidity self-sense for 20 seconds once;

- Temperature range 0°C–60°C;

- Relative humidity range 20%–90%;

- Temperature and relative humidity with memory of the MAX and MIN;

• Weather forecast;

- Nightlight;

- Key-tone.

KEY PRESS

[M] – Mode key [S] – Set (°C/°F)
[▲] – Up key [▼] – Down key [MEN] – MAX MIN
[SNOOZE/LIGHT]

OPERATION

1) Setting of time Power on the clock during 2 seconds and enter 12hr or 24 time format with the help of [UP] and [DOWN] keys Press [M] key to exit and display will have AM 12:00 or 0:00.
1 After 12/24 hours selected press the [S] key to enter time setting Hour position is twinkling press the Set key minute twinkling then press Mode key to exit setting.

2 In twinkle mode press the [▲] [▼] key to change.
3 In setting mode LCD returns to time mode if no any key for 20 seconds.

4 In time mode press the [S] key 2 seconds to enter time setting the operation is sameness over.

2) Setting of alarm In time mode press the [S] key dunring 2 seconds to enter time setting.
1 In alarm mode press the [S] key 2 seconds to enter alarm setting operation is time setting over sameness.

2 In alarm setting display exits setting if no any key will be pushed during 20 seconds.

3 In alarm mode press the [▲] key ON/OFF to see the alarm sign « » Alarm sounds during 1 minute when alarm is ON
with the sign « » is twinkling.

4 In alarm mode LCD returns to time mode if no any will be pushed during 20 seconds.

(RESET)

5) Setting of date.

In time mode press the [M] key twice to enter date mode with sign « » on right down of year.
1 In date mode press the [S] key 2 seconds to enter setting state: year month day is twinkling cycle and exit With [▲]
[▼] key to change.

2 Date range: up to Dec.31 2052.
3 In date setting week change itself from SUN to MON.
4 In date setting display exit setting state if no any key is pushed 20 seconds 5 In date mode display returns time mode if no any key is pushed 20 seconds.

6) Temperature/humidity measurements LCD displays currently temperature and humidity self-sense for 20 seconds once.
1 Power on default is °C Temperature range is 0°C – 60°C;
2 In time mode press the [S] key to change °C and °F;
3 Relative humidity range is 20% – 90%;
4 LCD will display « °C %» if system don’t measure temperature humidity or overtop range.

3) Snooze ON.

1 In alarm sounding press the Snooze/LIGHT key to break off while the snooze is ON itself; or after sounding for 1 minute the snooze is ON itself with sign « ».

2 If snooze is ON sound for 1 minute once every 4 minutes and 4 times while sign « » and « » twinkling.

3 While snooze sounding snooze function is available if press the Snooze key to break off sounding But if press the others key snooze function will be off.

4 During snooze ON snooze function is off itself if press any key.

4) Hourly alarm.

1 In alarm mode press the [MEN] or [▲] key twice ON/OFF hourly sign

2 Hourly sign and alarm sign ON/OFF:

» → « » and «

» → OFF.

3 There is a alarm buzzer every hour if hourly sign is ON.

7) MAX/MIN display & clean.

1 The system is update memory on current temperature/humidity real time.

2 In time mode press the [MEN] [▲] key once LCD show on

Max temperature/humidity with sign MAX 3 In time mode press the [MEN] [▲] key twice LCD show on

Min temperature/humidity with sign MIN 4 In time mode press the [MEN] [▲] key third time LCD show on current temperature/humidity 5 In time mode press the [MEN] [▲] key for 2 seconds to clean all

MAX/MIN memory and again renew current temperature/
humidity.

6 The system don’t save any memory if replace battery.

8) Weather forecast LCD display current weather status: sun (sunshine ) or sun & cloud (cloudy) or cloud & rain (rainy).
1 In temperature range 0°C ~60°C and humidity range 20%~45%

LCD display pattern ‘sun’.

2 In temperature range 0°C ~60°C and humidity range 46%~55%

LCD display pattern ‘sun & cloud’ 3 In temperature range 0°C ~60°C and humidity range 56%~90%

LCD display pattern ‘cloud & rain’.

4 If temperature is low 0°C or over 60°C LCD can’t display on relative humidity and weather status.

5 LCD can’t display on weather status if relative humidity display

9) Nightlight In time mode and non alarm sounding mode press the

[SNOOZE/LIGHT] key to on nightlight and self-off for 5 seconds

10) RESET/
Press [RESET] key to adjust when LCD display in a abnormal state.
