Инструкция для LENOVO-IBM Express x3250 M5 Rack 1U, 1xXeon E3-1270v3 4C (3.5GHz/8MB/1600 DDR3/80W), 8GB (5458E7G) на русском языке. Документ можно использовать для ознакомления с информацией, относящейся к данной модели.
Инструкция представлена в формате PDF, просмотр, скачивание на компьютер, смартфон бесплатно. Возможность печати зависит от используемой программы и настроек устройства. Содержание, структура и объём документа могут различаться в зависимости от модели, версии и редакции руководства. Перед использованием рекомендуется убедиться, что инструкция соответствует вашей модели.
System x3250 M5 1
System x3250 M5
Lenovo Press Product Guide
The System x3250 M5 single-socket 1U rack server is designed for small businesses and first-time server
buyers looking for a solution to improve business efficiency. It delivers several innovative features in a
compact 1U form factor with a competitive price. The System x3250 M5 provides next-generation
performance in an innovative and compact design with flexible configuration options, built-in security, and
systems management capabilities. It leverages the next-generation quad-core Intel Xeon processor
E3-1200 v3 product family technology.
Suggested use
: Small-to-medium businesses looking for file and printer servers, web serving, and small
business infrastructure.
The following figure shows the System x3250 M5.
Figure 1. The System x3250 M5
Did you know
The x3250 M5 offers a flexible and scalable design and a simple upgrade path to eight HDDs plus an
optical drive at the same time. The flexible onboard Ethernet solution provides two standard integrated
Gigabit Ethernet ports and two additional integrated Gigabit Ethernet ports with an optional software
feature for an on-demand upgrade without a need to buy additional hardware. Comprehensive systems
management tools with the next-generation Integrated Management Module II (IMM2) make it easy to
deploy, integrate, service, and manage.
The x3250 M5 includes features not typically seen in this class of system, such as standard RAID-0, 1,
and 10 with the ServeRAID C100 for simple-swap SATA models, remote control capabilities even when
the machine is powered off, and basic light path diagnostics on processor, memory, and hard drives. This
flexible 1U rack-mountable server is also highly upgradable and expandable, scaling from low-cost,
fixed-function models to feature-rich, highly available models.
